F.W. Bell 7030 - FW Bell 70 three-channel Advanced Gauss / Tesla-Meter

FW Bell 7030: The Model 7030 three-channel Advanced Gauss/Tesla-Meter from F.W. Bell is capable of simultaneously measuring and displaying seven different parameters per channel -- flux density, frequency, temperature, min, max, peak and valley. With its vector summation feature, the 7030 can measure and display a total of 27 different parameters. Key features include high-resolution, high-accuracy and high-speed with a large graphic electroluminescent display. The 7030 provides 50-kHz frequency response, temperature and frequency measurements, Auto Zero, Auto Range, Hold functions for Peak, Valley, Min and Max, corrected and uncorrected outputs for each channel and Vector Summation and angle. The Model 7030 provides the user with the units of gauss, tesla, Oe, A/m, and includes IEEE-488 and RS-232 communications ports and classifier relay output. The 7030 operates with Bell''s fifth generation Hall Effect probes. These probes provide temperature compensation and measurement readings (-40°C to +100°C) while monitoring the magnetic field. Applications range from basic magnetic measuring to sensitive complicated three-axis vector summing requirements.

by quote only

FW Bell 7030: The Model 7030 three-channel Advanced Gauss/Tesla-Meter from F.W. Bell is ca...

View Product

F.W. Bell 6010 - FW Bell Hall Effect Gaussmeter

FW Bell 6010: The Model 6010 Hall-effect gaussmeter represents the lastest innovations and state of the art designs from the world leader in magnetic measuring equipment. F.W. Bell''s exclusive Dynamic Probe Correction feature, along with temperature compensation, allows measurements up to 300kG with a basic accuracy of 0.25%. Key features include Peak Hold, Max/Min Hold, Auto Zero, Auto Range, Relative Mode and Temperature measurement. The Model 6010 allows the user to select Gauss, Tesla or Ampere/Meter readings. The Model 6010 also features a corrected analog output (+/- 3V Full Scale for each range), an RS-232 communications port, a rechargeable battery and probe temperature compensation. The Temperature measurement feature, used with the new 6000 Series 5th Generation Hall-effect gaussmeter probes, allow the user to take temperature readings (-40C to +85C) while monitoring the magnetic field. The easy-to-read large format alpha-numeric LCD, with dual 3 3/4 digit read outs, gives the user magnetic field flux density readings while also displaying temperature (or Peak Hold, or Max/Min Hold)

by quote only

FW Bell 6010: The Model 6010 Hall-effect gaussmeter represents the lastest innovations and...

View Product

F.W. Bell 5170 - FW Bell Hall Effect Gauss / Tesla Meter

FW Bell 5170: The 5100 Series Hall effect portable gaussmeters represent the most recent design from the world leader in magnetic measuring equipment. This new design incorporates the use of digital signal processing technology making it the world’s first hand-held gaussmeter to have a digital signal processor (DSP) on board. F.W. Bell’s exclusive Dynamic Probe Correction allows measurements from 0 to 30 kG with a basic accuracy of 1%. Key features include Auto Zero, Min./Max./Peak Hold, Auto Range and Relative Mode. Both models allow the user to select Gauss, Tesla or Ampere/Meter readings. The 5180 features a corrected analog output (±3V FS) and a USB communication port. The 5100 Series Hand-Held Gaussmeter’s built-in software eliminates the need for complex calibration procedures. User prompts on the custom formatted LCD allow fast, simple push button operation. All models come equipped with a detachable transverse probe, zero gauss chamber, instruction manual, hard carrying case, and four AA batteries. Axial, ultra thin transverse and low-field probes are available as options. Applications for the 5100 Series range from the most sensitive laboratory environment to the most rugged industrial setting. All instruments are CE compliant.

by quote only

FW Bell 5170: The 5100 Series Hall effect portable gaussmeters represent the most recent d...

View Product

F.W. Bell 5180 - FW Bell Hall Effect Gauss / Tesla Meter

FW Bell 5180: The 5100 Series Hall effect portable gaussmeters represent the most recent design from the world leader in magnetic measuring equipment. This new design incorporates the use of digital signal processing technology making it the world’s first hand-held gaussmeter to have a digital signal processor (DSP) on board. F.W. Bell’s exclusive Dynamic Probe Correction allows measurements from 0 to 30 kG with a basic accuracy of 1%. Key features include Auto Zero, Min./Max./Peak Hold, Auto Range and Relative Mode. Both models allow the user to select Gauss, Tesla or Ampere/Meter readings. The 5180 features a corrected analog output (±3V FS) and a USB communication port. The 5100 Series Hand-Held Gaussmeter’s built-in software eliminates the need for complex calibration procedures. User prompts on the custom formatted LCD allow fast, simple push button operation. All models come equipped with a detachable transverse probe, zero gauss chamber, instruction manual, hard carrying case, and four AA batteries. Axial, ultra thin transverse and low-field probes are available as options. Applications for the 5100 Series range from the most sensitive laboratory environment to the most rugged industrial setting. All instruments are CE compliant.

by quote only

FW Bell 5180: The 5100 Series Hall effect portable gaussmeters represent the most recent d...

View Product

F.W. Bell mA-2000 - FW Bell Clamp On Non-Contact Milliammeter

FW Bell mA-2000: The model mA-2000 provides non-contact measurement of very low DC and AC currents. It features an easy-to-read 3 1/2 digit display and analog output for connection to an oscilloscope or recorder.

by quote only

FW Bell mA-2000: The model mA-2000 provides non-contact measurement of very low DC and AC ...

View Product

Fluke 983 - Particle Counter

Fluke 983: Compact and easy to operate - Graphic liquid crystal display with backlight - Simple connection to computer or printer - Selectable sample time, count data, programmable delay - Set sample size to cubic feet or liters, set temperature measurements to Degrees Celsius or Degrees Fahrenheit - Data displayed in totalize or concentration modes - Automatic turn-off when battery voltage drops below safe operating level - Meets 115B9921:1997 and CE standards - Battery or AC operation with internal rechargeable battery - Protective holster - Rugged, hard shell carrying case

by quote only

Fluke 983: Compact and easy to operate - Graphic liquid crystal display with backlight - S...

View Product

Fluke CO-220 - Carbon Monoxide Meter

Fluke CO-220: Large LCD displays CO levels from 0 to 1000 ppm - Beeper triggers with increasing frequency as CO levels rise (Can be silenced in quiet environments) - MAX Hold function stores and displays the maximum CO level - Automatic sensor zeroing and self-test sequence upon start-up - Bright backlight allows easy screen viewing under dim lighting conditions - Automatic power-off after 20 minutes extends battery life - Replaceable sensor extends tool life - Includes C50 soft carrying case, battery and instruction sheet

by quote only

Fluke CO-220: Large LCD displays CO levels from 0 to 1000 ppm - Beeper triggers with incre...

View Product

Fluke CO-210 - Carbon Monoxide Accessory Probe

Fluke CO-210: As an accessory to a digital multimeter with DC millivolt inputs, the Fluke CO-210 displays CO level readings from 0 to 999 parts per million (ppm), with a resolution of 1 ppm and accuracy of /-3% - Detach the CO-210 cord and the probe acts as a stand-alone device, with an LED indicator and a beeper that triggers with increasing frequency as CO levels rise (The beeper can be turned off when silent operation is preferred) - Replaceable sensor extends tool life - Includes C50 Soft Carrying Case, battery (installed) and instruction sheet

by quote only

Fluke CO-210: As an accessory to a digital multimeter with DC millivolt inputs, the Fluke ...

View Product

Fluke 975V - AirMeter with Velocity Probe

The Fluke 975 AirMeter test tool raises indoor air monitoring to the next level by combining five powerful tools in one, rugged and easy-to-use handheld device. Use the Fluke 975 to optimize HVAC ventilation settings for ASHRAE 62 recommendations, actively monitor conditions that promote a productive environment, and quickly and accurately address occupant comfort complaints the first time. The Fluke 975 measures: Temperature Velocity Humidity CO2 CO

by quote only

The Fluke 975 AirMeter test tool raises indoor air monitoring to the next level by combini...

View Product

Fluke 705 - Loop Calibrator with Nist Cal with Data

The Fluke 705 Loop Calibrator is a cost-effective, integrated solution for calibration, repair and maintenance of current loops. It features: mA sourcing, simulation and measurement 0.02% accuracy and 0.001 mA resolution Simultaneous mA and % of span display Selectable step or ramp outputs 24 V Loop supply with mA measure 0-28 VDC measurement to check Loop Voltage Easy battery exchange without opening the case Compact case with separate protective holster Three year warranty

by quote only

The Fluke 705 Loop Calibrator is a cost-effective, integrated solution for calibration, re...

View Product
