GW Instek


GW Instek GDS-1072A-U - 70MHz, 2 Channel, Digital Storage Oscilloscope

The GDS-1072A-U series provide a unique solution. Operating at 70 MHz with a real-time sampling rate of 1GSa/s, the GDS-1072A-U employs MemoryPrime technology . Using MemoryPrime technology, the GDS-1072A-U is able to overcome the problems associated with memory constraints. High sample rates, rarely found in traditional DSOs, can be maintained over longer periods of time, without effecting performance. Coupled with the high resolution 5.7” color TFT display, with user-friendly interface USB device and host port make the GDS-1072A-U feature-rich. Furthermore, the GDS-1072A-U provide a lifetime warranty program!

by quote only

The GDS-1072A-U series provide a unique solution. Operating at 70 MHz with a real-time sam...

View Product

GW Instek GDS-3252 - 250 MHz, 2CH Digital Storage Oscilloscope

A Hi-tech DSO Platform The GDS-3000 Series is a new platform of 4-input channels, 500MHz bandwidth, 5GSa/s sampling rate, and VPO waveform display. The split screen feature has been designed to meet the requirements of multi-window & multi-signal tests in the research and the manufacturing fields. The optional power analysis software and the optional serial bus analysis software are available to facilitate the engineer''s tasks in testing and manufacturing of the associated products. Three new differential probes, GDP-025, GDP-050 & GDP-100, and two new current probes, GCP-005 ,GCP-020 ,GCP-100 and GCP-530 & GCP-1030, are coming along with the GDS-3000 Series to provide total solutions for a wide variety of applications in the industry, service and education market sectors. The GDS-3000 Series, a high-tech platform carrying thoughtful features, brings very high customer value to both general purpose market and professional market.

by quote only

A Hi-tech DSO Platform The GDS-3000 Series is a new platform of 4-input channels, 500MHz ...

View Product

GW Instek PEL-300 - 300W Programmable DC Electronic Load

The PEL-300 is a single channel, 300W, programmable DC electronic load. OVP, OCP, and OPP protect the PEL-300 from unexpected load conditions. The PEL-300 DC electronic load complies with major safety standards such as UL, CSA, and IEC to ensure safety. A high resolution of 20mV, 0.2mA and 0.33m (CV, CC, CR mode) ensures accurate load measurements. Sequence programming is simplified with save and recall options as well as extensive timer settings. It has self-test and software calibration features to reduce maintenance efforts. The PEL-300 is suitable for laboratory and production line applications,where safety and reliability are the top priorities.

by quote only

The PEL-300 is a single channel, 300W, programmable DC electronic load. OVP, OCP, and OPP ...

View Product

GW Instek GLP-1A - Logic Probe and Pulser

The GLP-1A logic pulser can be used to perform in-circuit testing of TTL, CMOS, and many other logic devices at a maximum of 50MHz. The GLP-1A is enhanced with a logic probe function with a minimum detectable pulse width of 10 ns, providing enough sensitivity for most applications. A Short 10 sec pulse width assures that no damage will occur to circuits whilst testing. With a weight less than 50g, a non-slip grip, and an external sync input, GLP-1A provides comfort and reliability for various troubleshooting tasks.

by quote only

The GLP-1A logic pulser can be used to perform in-circuit testing of TTL, CMOS, and many o...

View Product

GW Instek GDB-02 - Oscilloscope Education and Training Kit

Instek GDB-02: Oscilloscope Education and Training Kit for GDS-800 Series, GDS-1000 Series, GDS-2000 Series.

by quote only

Instek GDB-02: Oscilloscope Education and Training Kit for GDS-800 Series, GDS-1000 Series...

View Product

GW Instek LCR-817 - 10kHz High Precision LCR Meter

Test Frequency: 12Hz ~ 10kHz (489 steps) Option: RS-232C Interface, Including LCR-Viewer Software. Handler Interface (LCR-827/829). Test Condition and Test Result shown on the screen Simultaneously. 240 x 128 dot Matrix LCD Display. Absolute Value, ΔValue, and Δ% Measurement Display. R/Q, C/D, C/R, L/Q Test Modes. 100 Sets Memory for Save/Recall of Setup State. 0.05% High Measurement Accuracy (LCR-817/819). Continuously Variable Frequencies. Test Frequency: 12Hz to 100kHz (503 steps)

by quote only

Test Frequency: 12Hz ~ 10kHz (489 steps) Option: RS-232C Interface, Including LCR-Viewer ...

View Product

GW Instek LCR-819 - 100kHz High Precision LCR Meter

Test Frequency: 12Hz to 100kHz (503 steps) Continuously Variable Frequencies. 0.05% High Measurement Accuracy (LCR-817/819). 100 Sets Memory for Save/Recall of Setup State. R/Q, C/D, C/R, L/Q Test Modes. Absolute Value, ΔValue, and Δ% Measurement Display. 240 x 128 dot Matrix LCD Display. Test Condition and Test Result shown on the screen Simultaneously. Handler Interface (LCR-827/829). Option: RS-232C Interface, Including LCR-Viewer Software.

by quote only

Test Frequency: 12Hz to 100kHz (503 steps) Continuously Variable Frequencies. 0.05% High...

View Product

GW Instek LCR-821 - 200kHz High Precision LCR Meter with RS-232C Interface

The LCR-800 Series are high-end digital LCR meters for component/material measurements, applicable to various R&D activities and assembly lines. The large 240 x 128 dot matrix LCD display provides ampleroom for two measurement items and setup parameters allowing you to grasp measurement results quickly. All test modes are able to measure supplementary factors such as, R/Q, C/D, C/R, and L/Q. The LCR-821 also contains precise resistance measurements as a combination of absolute value and phase angle. 100 sets of measurement setup memory allow sharing a single unit among multiple testing conditions or sites. For a better viewing experience with a standard PC monitor, proprietary Windows based software is accessible via the RS-232C terminal. The handler interface is also a standard feature for LCR-826/827/829.

by quote only

The LCR-800 Series are high-end digital LCR meters for component/material measurements, ap...

View Product

GW Instek GFC-8270H - 2.7GHz Intelligent Counter

The GFC-8000 Series performs virtually all of the counting measurements required in laboratories, in terms of both period and frequency. A bright red 8 digit LED display with an included overflow indicator provides a clear view. Both models feature a stable time base with a maximum resolution of 100nHz and 10nS at 1Hz for frequency and period measurement, respectively. Gate time can be configured for fast response (5 digits/10ms) or accuracy (7 digits/s) for more control. For high frequency needs, the GFC-8270H can operate at up to 2.7GHz. The GFC-8000 Series features easy operation with a simple front panel interface, suitable for both portable and bench-top use.

by quote only

The GFC-8000 Series performs virtually all of the counting measurements required in labora...

View Product

GW Instek GFC-8010H - 120MHz Intelligent Counter

The GFC-8010H performs virtually most of the counting measurements required in laboratories, in terms of both period and frequency. 8 digits LED display with distinctive red color and overflow indicator provides fast and clear view. With easy operation of all functions neatly organized on the front panel, compact size suitable for both portable and bench-top usage, the GFC-8010H serves users as a handy reference.

by quote only

The GFC-8010H performs virtually most of the counting measurements required in laboratorie...

View Product
